HAMMER H series power amps, featuring a world-class condenser, boast exceptional signal accuracy and precision for all frequency bands, and they can even achieve maximum output with minimal power consumption thanks to the application of the latest Class-3H circuit technology. Above all, by applying a high-cost analog trans-type amplification method, the sound produced from the speakers is unbelievably clean and clear, even at low pitch frequencies.


Main Characteristics

– Application of the latest Class-3H technology

– Application of a condenser with the highest specification

– Application of an analog trans type amplification method

– Near-perfect durability

– Two-year warranty


Model: H1200

Output power – (AC 220V/60Hz.150W)

– 8Ω Stereo(FTC 20Hz~20kHz @0.5% THD): 1200W

– 4Ω Stereo(FTC 20Hz~20kHz @0.5% THD): 2400W

– 2Ω Stereo(FTC 20Hz~20kHz @0.5% THD): 2800W

– 8Ω Bridge(FTC 20Hz~20kHz @0.1% THD): 2400W

– 4Ω Bridge(FTC 20Hz~20kHz @0.5% THD): 5600W

S/N (20Hz~20kHz, 8Ω): 99dB

THD+N: < 0.5%

Input Impedence: 20kΩ (Balance)

Frequency Response: 20Hz~20kHz@1W

Circuit Type: H3 Class

Damping Factor: > 900 (100~400Hz, 8Ω)

Cross talk: > 65dB

Slew Rate: > 10v/µs

Cooling System: 2 Fans

Connector Input: Neutrik® XLR-F

Connector Output: Neutrik®Speakon NL4

Control: Volume, Stereo/Parallel/Bridge, Bridge Denote, Low Cut

Protection: Short, Auto Limited, Over load, AC/DC Protection

Product Dimensions (mm): 483mm x 560mm x 140mm

Weight: 33.3kg
