AK 25

Characteristics of AK Series are medium and large size compression driver, powerful magnet power, surround and low pitch unit for enduring such strong power, and deep and punching sound naturally expressing the whole frequency without biased on a certain frequency. Detailed network design made under tests for a long time provides excellent acoustic sound performance without getting lost in rich low pitched sounds. This allows audiences to immerse in the natural and clear performance. In addition, an enclosure made with plywood for specially bonded speaker is our special technology for controlling unnecessary resonance from speaker’s overtone.

* Performance stage

* Music Club

* Church

* Movie theater

* Conference

SPECIFICATIONS

Model: AK-25 (Dual 15″ 2way full range system)

Power Handling: 1000W (Cont) / 2000W (Prog) / 4000 (Peak)

Frequency Range: 42Hz – 20KHz

Frequency Response: 45Hz -20KHz

Average Sensitivity: 102dB(W/m)

Max SPL: 134dB(PEAK/1M ±3dB)

Nominal Impedance:

Nominal Directivity: 90º(H) x 50º(V)

Low Frequency Driver: 100mm(4″) Coil / 2 x 380mm(15″) woofer / 2 x 190mm Magnet

High Frequency Driver: 75mm(3″) Coil Compression driver

Connectors: 2 x Speakon® NL4MP (1+/1- Input & Link)

Pole Mount: None

Enclosure: CNC made with tongue and grove assembly 18mm birch plywood

Finish: Touring grade textured black Paint coating

Dimensions: 480mm(W)×1150mm(H)×445mm(D)

Weight: 51.1kg
